Device characteristics

1, DGS-2000F type quantitative ton packaging machine is composed of high precision (0.02%) sensor and high resolution control instrument measurement and control system, high precision, stable performance is good.

2, feeding mechanism adopts frequency converter to control screw speed, quantitative control feeding, packaging speed.

3, a wide range of packaging, adjustable in the range of 200 ~ 2000kg. Packing suitable for large packing bag.

4, parameter setting, weighing calibration is simple and easy to understand, easy to operate.

5, with a variety of communication interface, can be used with the computer network for a variety of data processing.

Two, equipment composition

1, screw feeder

2, weighing frame

3, frame

4, pneumatic hanging bag, bag pressing device.

5, shaking table

6, electrical box

7, dust collecting device

Three, structural principle

1, the variable-speed feeding mechanism: is composed of motor, belt drive, screw axis, feeding mouth, feeding mouth with a vacuum port, the motor speed by the electrical box control speed, bring material from the hopper into the package bag through the spiral.

2, weighing frame: weighing frame and sensor connection, the weight of the material is transmitted to the electrical box, the operation of the whole machine controlled by the electrical box. The lifting cylinder of the weighing frame hook the angle of the packing bag.

3 electric box: the external signal and sensor signal transmission to the electrical box, electric box through the preparation of the program, control feeding motor start, stop, speed, the lift of the cylinder.

Four, working process

Will be tons of packaging bag in feeding mouth, the packaging bag four horn hung on the cylinder, press the "start" button, then a compressed bag cylinder starts to work and to suppress the bag, cylinder packaging bag corner distraction, controller of the packing bag weight automatic removal, screw rotation quickly material poured into the bag, shaking table vibration will material tap, with air bag together with the overflow of the dust by the dust collector is sucked by dust, to be fast to the setting value, feeding, screw speed reduction and slow, stop the vibration, to the set value, feeding stop. Error <0.3%. When the pressure cylinder cylinder will loosen the bag bag, packing bag four angle will loosen, forklift bags sent.

Note: the above working process is automatic feeding process. Working process can also be changed manually feeding process, only the button "automatic / manual button is arranged in the manual, press the" pressure bag (promote) "button, the bag is tightly pressed and press the manual fast plus" button is fast charging, to be fast to set value when press "manual slow plus" button is slow feeding, press the "stop" button until the set value, feeding process end.

Five, the main functions and technical parameters

Model DGS-2000F

Tons of bags

Feeding range 500 - 2500kg

Packing speed 0-40 bag / hour

Precision static precision 0.1%FA.OIML III dynamic accuracy 0.3%

Gas source 0.4 ~ 0.6MPa, the consumption of 2M3/h

Power AC380V

Total power 5.5.kw

Dimension (length * width * height) 1600x1600x2800
