The packaging machine is my company research and development of a new generation of intelligent packaging machine, weighing and packing the material according to the principle of electronic weighing, adopted fast, medium and slow speed spiral feeder, with characteristics of high precision, fast speed, no dust pollution,. The utility model is suitable for the quantitative packing of powder, powder mixed material and sheet material.

Products widely used in chemical, pharmaceutical, food industry. Such as raw materials, flour, milk powder, starch, sugar, additives, fertilizers, feed, plastic powder, new building materials industry.

Unit mainly consists of four parts: automatic weighing and packing machine, conveying device, sewing machine, feeding machine. With a reasonable structure, beautiful appearance, convenient operation, weighing accurate characteristics.

Equipment characteristics:

Full stainless steel production process

LCD screen, PLC control technology, easy to operate

Class production, Nissan, cumulative production automatic storage

Unique broken arch technology to prevent the spiral feeding material block overhead

Weighing control system in accordance with the requirements of IP54 (dust and waterproof) design

Independent suspension sensor, signal transmission and stability, to ensure the accuracy of weighing

Solve the same kind of product pneumatic clamp hand to open the material bag to drop the powder material overflow, turn the bag phenomenon

Main technical parameters:

Model AT-DGS-50F

Suitable material powder, mixed material

Metering range 5-50 kg

Packaging precision 0.2-0.5%

Packing speed 3-6 bag / min

Feeding mode single screw

Gas pressure 0.4-0.6Mpa

Gas consumption 1 m3/h

Power / power 380V/2.2KW

External dimension (CM) 300 * 150 * 250
